Venus - SolarPath Sun Solutions

Venus™

Description

The EDGE series redefines how you think about LED linear lighting. It provides unmatched illumination performance and significant energy savings coupled with modern design elements.

Key Features

? Rugged extruded aluminum housing.
? Modular design allows for easy installation, replacement and maintenance.
? Corrosion resistant polyester powder painted 100?m thickness.
? Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.
? Over 20 optical lenses are available for virtually any application.
? Surface mount and suspension mount available.
? Multiple units are linkable.
? Multiple lighting control options are available, e.g. motion sensor, DALI, 1-10V.
? 10 years limited warranty available.

Technical Specifications

	Venus™
Power	60-150W
Input	120-277VAC or 220-240VAC or 347-480VAC or 12-24VDC
PF	>0.95
THD	<20%
L85	>60,000H
Operating Temperature	-40F- 122F
Efficacy	120-140lm/W
ANSI CCT	3000K/4000K/5000K/5700K
Min CRI	70* or 80 or 85
IP Rating	IP67
SPD	Optional
Dali	Optional
1-10V	Optional
Photocell	/
Smart Control	Optional
Optic(IESNA)	Type I, Type II, Type III, Type IV, Type V
Color Options	Black/Grey
