SP-SGL

About Product

The design of the garden light absorbs energy from the universe and combines it with a high efficiency solar panel and LEDs. It adopts advantage technics such as micro-controller and combines with integrated design to achieve multiple features such as low power consumption but high brightness, long lifespan and maintenance free, with waterproof function and great thermal dissipation.

Technical Specifications




SP-SGL

Lighting Technology LED Light Technology
LED Power 20W/40W
Brightness 3,000lm/6,000lm
CRL CRI>70
LED Color Temperature 3000°K – 6000°K
Battery Enclosure Integrated Inside Pole
Solar Panel Power 180W 18V/ 360W 36V
Solar Panel Type Mono-crystalline photo-voltaic panel
Battery Type LifoPO4 Lithium Battery
Battery Capability 268.8WH 21AH 12.8V/ 537.6WH 21AH 25.6V
Working Temperature -4°F – 158°F
Working Mode 1H 100%- 3H 80%- 8H 20% (Can changed per to solar
radiation)
IP Rating IP68


Spec Sheet

Download Spec Sheet™

IES

Download IES Here

Install Manual

Click here to download
