Key Features
- Beautiful and modern appearance, simple and fashionable. Use of solar green energy, environment friendly, saving more.
- Low voltage driving, meet the Europe standard of CE RoHS FCC.
- No Hg, Pb or other hazardous materials, no radiation, human safety
- IP65 grade, TVS lightning protection.
- Long lifetime of whole lamp, low maintenance costs.
Technical Specifications
| |
Excel 1000™
|
Excel 2000™
|
Excel 3000™
|
Excel 4000™
|
Excel 5000™
|
| LED Power |
15W |
20W |
30W |
40W |
50W |
| Solar Panel |
50W/18V |
65W/18V |
80W/18V |
100W/18V |
150W/18V |
| Lithium Battery |
170WH/12.8V |
212WH/12.8V |
340WH/12.8V |
424WH/12.8V |
610WH/11.1V |
| LED qty |
40pcs |
40pcs |
60pcs |
60pcs |
60pcs |
| Luminous Flux |
1800-2100lm |
2500-2800lm |
3600-4200lm |
5000-5600lm |
7200-7500lm |
| Charge Time(full sunlight) |
5.5 hrs |
5.5hrs |
7hrs |
7hrs |
6.5hrs |
| Lamp Body |
28.5*13.9*11in |
28.5*13.9*11in |
28.5*13.9*11in |
28.5*13.9*11in |
28.5*13.9*11in |
| Panel |
25.5*23.4*2.44in |
28.5*25.9*2.44in |
32.8*28.7*2.44in |
39.5*29.7*2.55in |
26.2*51.9*2.44in |
| Led Chip |
Bridgelux |
Bridgelux |
Bridgelux |
Bridgelux |
Bridgelux |
| Color Temperature |
3000-6500K |
3000-6500K |
3000-6500K |
3000-6500K |
3000-6500K |
| CRI |
70Ra |
70Ra |
70Ra |
70Ra |
70Ra |
| Light control voltage |
5V |
5V |
5V |
5V |
5V |
| Light Distribution |
Bat wing with
polarized light |
Bat wing with
polarized light |
Bat wing with
polarized light |
Bat wing with
polarized light |
Bat wing with
polarized light |
| Lighting Time |
2-3 days |
2-3 days |
2-3 days |
2-3 days |
2-3 days |
| Sensor Distance |
16.4-32.8FT |
16.4-32.8FT |
16.4-32.8FT |
/ |
| Sensor Time |
20-30s |
20-30s |
20-30s |
/ |
/ |
| Working Temperature |
-4F- 140F |
-4F- 140F |
-4F- 140F |
-4F- 140F |
-4F- 140F |
| Lifetime |
50000hours |
50000hours |
50000hours |
50000hours |
50000hours |
| Material |
High quality aluminum
alloy, die-cast aluminum |
High quality aluminum
alloy, die-cast aluminum |
High quality aluminum
alloy, die-cast aluminum |
High quality aluminum
alloy, die-cast aluminum |
High quality aluminum
alloy, die-cast aluminum |
| Pole Top Diameter |
2.75in |
2.75in |
2.75in |
2.75in |
2.75in |
Mounting Height
(recommendation) |
16.4-32.8FT |
16.4-32.8FT |
16.4-32.8FT |
16.4-32.8FT |
16.4-32.8FT |
Installation spacing
(recommendation) |
32.8-98.4FT |
32.8-98.4FT |
32.8-98.4FT |
32.8-98.4FT |
32.8-98.4FT |
